Gravity Convection Oven NGCO-100

Gravity Convection Oven NGCO-100 uses natural convection mechanism for uniform distribution of heat. It offers the temperature range of RT + 10 to 200 ℃ and has temperature stability of ± 1 ℃. Design excludes fan unlike mechanical convection ovens to ensure quiet operation. Exterior of the Oven is composed of 304 stainless steels, providing resistance to corrosion.

---

Get Quote Catalog

Specifications

Chamber Volume	56 L
Temperature Range	RT + 10 to 200°C
Ambient temperature	+ 5 to 35 ℃
Display Resolution	0.1 °C
Temperature Stability	± 1 °C
Shelves	2 pcs
Power supply	AC 220 V, 50 Hz
Power	1000 W
Internal Dimension	400 × 330 × 415 mm
External Dimension	540 × 550 × 720 mm
Weight	66 Kg

Features

• Capacity of Gravity Convection Oven is 56 L
• Polished mirror surface guarantees effortless cleaning
• Even heat regulation guarantees consistent results
• User friendly controls for operating the device
• PID controller with overtemperature alarm improves safety factor
• RS485 connector smoothens data transfer
• Timing function enhances efficiency

Applications

• Gravity Convection Oven is a versatile tool known for drying, sterilizing, and heat-treating samples across industrial sectors like food, pharmaceuticals, textiles, agriculture, etc.

Optional Accessories

Printer

---

Independent temperature limiting alarm system

---

RS485 connector

---

Intelligent programmable temperature controller

---

Test hole (Φ 25 mm or 50mm)
