Refrigerated and Heating Circulator NRHC-409

Refrigerated and Heating Circulator NRHC-409

Refrigerated and Heating Circulator NRHC-409 is designed to support a wide temperature control range of -80°C to 200°C. It uses Grade A silicone oil to ensure reliable thermal conductivity. This unit features a closed-loop circulation system to prevent fluid loss and contamination. It has a built-in circulation pump with a flow rate of 30L/min for efficient fluid movement. Our circulator facilitates safe operation through multiple protection mechanisms.


$17,250.00

Catalog

Specifications

Capacity 100L
Temperature range -80°C to 200°C
Ambient temperature 5 to 35°C
Temperature accuracy ±0.1°C
Temperature sensor PT100
Room humidity ≤70% ventilation
Flow 30L/min
Lifting head 25M
Pressure ≤0.2MPa
Refrigerant R22
Heat exchange area 2.5㎡
Body material Cold plate spray anticorrosion
Compressor type 10P
Compressor quantity 2
Screen display LCD screen, key operation
Safety protection Delay, overcurrent, overheating, over-temperature, phase sequence, and phase loss protection
Compressor power 14700W
Cooling capacity 46480W
Heating power 9000W
Total power consumption 24450W
Power supply 3phase 380V/50Hz
Outer loop interface 6 points wire mouth with 6 points × 3 meters metal circulation pipe two
Circulating fluid Grade A silicone oil
Product dimension 1060×1600×1420 mm
Packaging dimension 1650×1100×1540 mm
Net weight 456 kg
Packaging weight 500 kg

Features

  • High flow capacity
  • Electric heating system
  • Dual compressor setup
  • R22 refrigerant cooling
  • Corrosion-resistant body
  • LCD screen display
  • Self-diagnosis function
  • External loop interface

Applications

  • Refrigerated and Heating Circulator NRHC-409 is used for precise temperature control in processes requiring rapid heating and cooling. It is commonly applied in chemical synthesis, pharmaceutical production, biotechnology, and laboratory research.

Ask Expert

FAQ for Refrigerated and Heating Circulator NRHC-409

1: Is the Refrigerated and Heating Circulator NRHC-409 safe to operate continuously?

Yes, our Refrigerated and Heating Circulator includes multiple safety protections such as over-temperature, overcurrent, phase sequence, and phase loss protection. These features offer reliable performance even during extended operation.

2: Is Refrigerated and Heating Circulator NRHC-409 easy to connect to other equipment?

Yes, the external loop interface with metal circulation pipes makes it simple to connect the unit to reactors or other thermal systems, enabling seamless integration into your setup.

3: Is the Refrigerated and Heating Circulator NRHC-409 energy efficient for industrial use?

Despite its high power capabilities, our Refrigerated and Heating Circulator is designed for efficient operation. The dual-compressor system and intelligent thermal management optimize performance while reducing energy waste.

4: What kind of maintenance does the closed-loop system require?

The closed-loop system is designed to minimize contamination, but occasional inspection for leaks or moisture intrusion is recommended. Always keep the system sealed when not in use.

5: How do I clean the Refrigerated and Heating Circulator NRHC-409 externally?

Use a soft, dry, or slightly damp cloth to wipe down the body. Avoid using harsh chemicals or solvents to prevent damage to the anti-corrosion coating.


Refrigerated and Heating Circulator NRHC-409

Refrigerated and Heating Circulator NRHC-409

Related Models Of Refrigerated And Heating Circulator

Labnics Refrigerated and Heating Circulators are designed to provide both cooling and heating functions for accurate temperature regulation. They use a PID controller to maintain precise stability and uniformity. These units feature a powerful pump for consistent heat distribution and efficient fluid flow. They include a user-friendly interface for easy operation and monitoring. Our circulators are equipped with advanced safety mechanisms for reliable protection.
