Automatic Melting Point Meter NMPM-206 accurately measures melting points from room temperature to 300°C. It automatically records the melting range, initial melting, and final melting for precise analysis. Our unit offers a real-time spectrum display for accurate melting point and distance measurement. This meter features a self-diagnosis function for enhanced reliability and optimal performance. It features a 10.4-inch TFT color touchscreen, providing an intuitive and user-friendly interface.
$5,250.00
| Temperature Range | Room temperature to 300°C |
| Detection Method | Fully automatic |
| Processing Capacity | 4 pcs per batch |
| Test Mode | Melting point |
| Temperature Resolution | 0.01°C |
| Heating Rate | 20°C from ambient to plateau and 2°C/min to melt |
| Temperature Control Mode | PID precise temperature control, fully enclosed furnace body |
| Accuracy | ±1°C (200°C) ±2.5°C (300°C) |
| Repeatability | ±0.1°C at 0.1°C/min |
| Magnification | 9 times |
| Display Method | 10.4-inch TFT color touchscreen |
| Data Storage | 32GB |
| Map Save | 200 groups |
| User Management | YES / Level 4 authority |
| Audit Trails | YES |
| Electronic Signature | YES |
| Export File Verification | Advanced protection MD5 |
| Printing Method | WiFi, serial port |
| Export Formats | PDF & EXCEL |
| Data Interface | USB, RS232, SD, WiFi, RJ45, U disk |
| Small Capillary Size | OD: Φ1.3mm ID: Φ1.1mm |
| Power Supply | 230V, 50Hz |
| Dimensions | 400 × 280 × 330 mm |
| Weight | 4.1 kg |
Labnics Melting Point Meters feature an adjustable heating rate, allowing precise temperature control. They provide an intuitive interface for easy operation and parameter setting. They support multi-sample testing, allowing simultaneous analysis of multiple samples. These meters include a self-diagnosis function that detects system errors and ensures reliable operation. Our units provide efficient data management, enabling easy data transfer and storage.
