Product Data Sheet · Laboratory Equipment
Biological Microscope NBM-108 features a binocular viewing head inclined at 45⁰ for comfortable and flexible viewing. It offers 10x magnification with a 20mm field of view for improved specimen observation. The double-layer mechanical stage features a graphite-coated surface for enhanced durability and ease of movement. It includes Kohler illumination with LED lights for consistent brightness. Our microscope has precision metal cog-wheel gearing for smooth, accurate condenser adjustments.
| Optical System | Finite Optical System |
|---|---|
| Viewing Head | Seidentopf Binocular Viewing Head Inclined at 45⁰ 360⁰Rotatable |
| Eyepiece | Wide Field Eyepiece WF10X/20mm |
| Nosepiece | Quadruple Nosepiece |
| Objective | Finite 195 Series Achromatic Objectives 4X 10X 40Xs 100Xs(oil) |
| Condenser | Abbe Condenser NA1.25 with Diaphragm, Filter |
| Focusing Unit | Coarse and Fine Adjustment Fine Division: 0.001mm Coarse Stroke: 37.7mm/Rotation Fine Stroke: 0.1mm/Rotation Moving range: 24mm |
| Stage | Double Layer Mechanical Stage: 142 × 132mm Moving Range: 75mm × 50mm |
| Illumination | External Illumination, 3W/LED |
| Packaging Dimensions | 540 × 330 × 400 mm |
| Net Weight | 7 Kg |
| Gross Weight | 9.5kg |
