Vertical Autoclave NVA-204

Vertical Autoclave NVA-204

Vertical Autoclave NVA-204 has a 35L capacity, providing ample space for sterilizing various materials. It features a timer range from 0 to 60 minutes, allowing users to easily adjust the sterilization cycle. Our unit comes with an indicator light to show the operational status. It uses a hand-wheel quick-open door for easy access and secure sealing. This vertical autoclave includes a water-lack protection mechanism to prevent operation without sufficient water.


$2,725.00

Catalog

Specifications

Capacity 35L
Chamber volume 318×450mm
Working temperature 134°C
Working pressure 0.22Mpa
Temperature range 105°C to 134°C
Maximum working pressure 0.23Mpa
Heat average ≤±1°C
Timer range 0 to 60 min
Body Stainless steel
Door Wheel-type, quick-open door
Total CBM 0.33CBM
Power consumption 1×2.5kW
Power supply AC220V, 50Hz
Overall dimension 470×450×1020mm
Packaging dimension 540×540×1140mm
Gross weight 81kg
Net weight 63kg

Features

  • Standard sterilizing baskets
  • Durable stainless-steel structure
  • Advanced safety mechanisms
  • Self-inflating airtight seal
  • Double-scale pressure gauge
  • Low maintenance required

Applications

  • Vertical Autoclave NVA-204 is used to eliminate bacteria, viruses, and other pathogens through high-pressure steam sterilization. It is widely applied in dental offices, pharmaceutical industries, veterinary clinics, and research laboratories.

Ask Expert

FAQ for Vertical Autoclave NVA-204

1: How is the sealing of the Vertical Autoclave NVA-204 ensured during operation?

The Vertical Autoclave uses a self-inflating airtight seal that automatically expands during pressure build-up to create a secure closure. This prevents steam leakage and maintains internal pressure for efficient sterilization.

2: How does the pressure and temperature control work?

Our Vertical Autoclave operates at a working pressure of 0.22 MPa and maintains a temperature of up to 134°C, with a maximum pressure of 0.23 MPa. A double-scale pressure gauge helps users monitor these parameters with precision.

3: How can I tell when the cycle is complete?

The Vertical Autoclave features an indicator light that signals the operational status, helping monitor progress. Users can also set the timer, which automatically ends the cycle at the chosen duration.

4: How often should the Vertical Autoclave NVA-204 be cleaned?

It is recommended to clean the chamber and sterilize baskets after each use to prevent residue buildup. Regular cleaning ensures efficient performance and extends the lifespan of the unit.

5: What should be used to clean the Vertical Autoclave NVA-204?

Use a soft cloth and mild, non-abrasive detergent to clean the internal chamber and external surfaces. Avoid harsh chemicals or scrubbers that may damage the stainless-steel body or seals.

6: Is the Vertical Autoclave suitable for use in laboratories with limited space?

Yes, the vertical design is especially suited for compact spaces. It takes up minimal floor area while offering sufficient internal volume for sterilizing multiple items at once. This makes it a preferred choice in many research and clinical labs.

7: Can the Vertical Autoclave handle different types of loads, like liquids and instruments?

Yes, our Vertical Autoclave is designed to sterilize a wide range of materials, including liquids, surgical instruments, culture media, and lab glassware. With adjustable temperature and time settings, it adapts easily to various sterilization needs.

8: How durable is the construction of the Vertical Autoclave?

The Vertical Autoclave is built with high-grade stainless steel that resists corrosion and ensures a long operational life. The rugged outer body and quality internal components are designed to withstand repeated high-temperature cycles. This ensures dependable performance over time.

9: Is the Vertical Autoclave easy to maintain?

Routine cleaning and basic maintenance, like water tank refilling and gasket checks, are straightforward. The design allows easy access to internal parts for inspection. With proper care, it continues to perform efficiently with minimal servicing.


Vertical Autoclave NVA-204

Vertical Autoclave NVA-204

Related Models Of Vertical Autoclaves

Vertical Autoclave are designed with built-in safety mechanisms that prevent damage and ensure user safety. Our vertical autoclaves are designed to operate efficiently, ensuring minimal energy consumption. They feature intuitive controls and clear displays for easy monitoring. These autoclaves are crafted from high-quality stainless steel, providing exceptional durability. They include an electronic lock system that secures the door during the sterilization cycle.
