Recirculating Chiller NRC-303 supports a temperature range from –120°C to room temperature, enabling ultra-low temperature applications. It delivers a flow rate between 30 to 50 L/min for efficient fluid circulation. This unit utilizes a digital temperature display for accurate temperature control. It has a PT100 temperature sensor to provide precise thermal monitoring. Our chiller is designed with multiple safety features to ensure secure and reliable operation.
$23,675.00
Specifications
| Tank capacity | About 98L |
| Temperature range | -120°C to RT |
| Room Temperature | 5 to 35°C |
| Temperature accuracy | ±0.1°C |
| Temperature sensor | PT100 |
| Room humidity | ≤70% ventilation |
| Flow | 30 to 50L/min |
| Lifting head | 10 to 12M |
| Pressure | ≤0.4MPa |
| Heat exchange area | 78㎡ |
| Air volume | 13600m³/h |
| Refrigerant | R22 |
| Condensing coil | Φ19 Copper tube nickel plated |
| Material | Cold plate spray anticorrosion |
| Compressor type | 10P |
| Compressor quantity | 3 |
| Screen display | LCD screen, key operation |
| Safety protection | Delay, overcurrent, overheating, phase sequence, phase loss protection |
| Compressor power | 22050W |
| Cooling capacity | 69720W |
| Total power consumption | 23050W |
| Power supply | 380V 50Hz 3phase |
| Outer loop interface | Φ19mm |
| Tank dimension | Φ500×500 mm |
Features
Applications
Ask Expert
FAQ for Recirculating Chiller NRC-303
1: Can this Recirculating Chiller NRC-303 be integrated with other lab equipment?
Our Recirculating Chiller can be easily combined with devices like rotary evaporators, vacuum freeze-drying systems, and circulating water vacuum pumps. This compatibility enhances its flexibility in complex laboratory setups.
2: How powerful is the cooling system?
The Recirculating Chiller is equipped with three 10P compressors and delivers a cooling capacity of up to 69,720W. This ensures rapid temperature reduction and efficient operation even under high loads.
3: What kind of maintenance does this Recirculating Chiller NRC-303 require?
Routine maintenance includes checking the refrigerant levels, inspecting connections, and cleaning filters. Its robust design and quality components reduce the frequency of service needs.
4: How does the Recirculating Chiller NRC-303 protect itself during a power issue?
The Recirculating Chiller features phase sequence and phase loss protection to safeguard the unit against electrical faults. This is crucial for uninterrupted performance and component longevity.
5: Can the Recirculating Chiller be used in continuous 24/7 operation?
Yes, the Recirculating Chiller is built for heavy-duty applications and can handle round-the-clock operation when needed. Its stable cooling and protective features support extended use without compromising performance.
Labnics Recirculating Chiller features automated water level detection, to maintain optimal water levels. They feature a compact design with a user-friendly touchscreen for easy monitoring. These units are equipped with a microprocessor PID controller for precise temperature control. Our recirculating chillers are built with durable steel construction for long-lasting performance. They come with high-efficiency pumps that ensure steady flow rates.
