Multi-gas Analyzer NMA-250
Multi-gas analyzer NMA-250 is a portable analyzer designed for measurement, analysis, monitoring and control of gas output. Equipped with four gas detector sensors for oxygen, combustibles, hydrogen sulfide and carbon monoxide. The Acrylonitrile- Butadiene- Styrene body shell is temperature-chemical resistant and durable at low temperatures.
| Sensor | High sensitivity sensor |
| Sampling method | Diffusion |
| Detection range | H2S, CO, O2, SO2, CO2, Cl2, NH3, NO2, O3, HCN, PID (VOCs) and combustibles |
| Operating humidity ( non-condensing ) | 15 % to 90 % RH |
| Operating temperature | ( -10 °C to 40 °C ) |
| Display panel | 2 + 2 digit LCD display |
| Data storage | 9600 pieces data record |
| Pumping tube length | - |
| Alarm system |
Audible ( > 90 dB ) Bright dual color LEDs Integrated vibrating alert |
| Alarm error | ≤ ± 3 % |
| Body shell material | Acrylonitrile – Butadiene- Styrene polymer, slip silicone |
| Battery life ( rechargeable ) | 10 + hours |
| Power supply | 3.7 V Li battery |
| Dimensions ( W x H x D ) | 70 x 38 x 132 mm |
| Weight | 300 g |
Used for the measurement and analysis of gas output or leakage in ceramic, iron-steel industry, thermal treatment, electronic, agricultural, biochemical facilities for environmental pollution regulation
| Accessory No | Accessory | Units |
| 1) | Operator’s manual | 1 |
| 2) | Detection probe | 1 |
| 3) | Calibration hose | 1 |
| 4) | USB cable | 1 |
| 5) | Charger | 1 |
| 6) | Conversion plug | 1 |
| Sensor | High sensitivity sensor |
| Sampling method | Diffusion |
| Detection range | CO, O2, Cl2, SO2, O3, CO2, CH4, H2S, NH3, NO, NO2, H2, LEL, LPG, PID, EXP, CH4 (IR), C3H8 (IR) |
| Operating humidity ( non-condensing ) | 15 % to 90 % RH |
| Sensor | Non-dispersive infrared sensor |
| Sampling method | Diffusion |
| Detection range | CO2,CH4 (IR) |
| Operating humidity ( non-condensing ) | 15 % to 90 % RH |
| Sensor | High sensitivity sensor |
| Sampling method | Diffusion |
| Detection range | O2, CH4, CO, H2S, SO2, Cl2, NH3, NO2, NO, H2, HCl, HCN, CH4, PID (VOCs), CO2, C3H8 and O3 |
| Operating humidity ( non-condensing ) | 15 % to 90 % RH |
| Gas detected | Acetylene C2H2 |
| Sampling | With internal sampling pump, flow rate is up to 1 L/min, ten grades of pumping suction for selection |
| Data logger | 100,000 data sets can be stored, with a storage space limit of 5S |
| Measuring range | 0 to 50 ppm |
| Sensor | High sensitivity sensors |
| Sampling method | Diffusion |
| Detection range | CO, O2, Cl2, SO2, O3, CO2, CH4, H2S, NH3, NO, NO2, H2, LEL, LPG, PID, EXP, CH4 (IR), C3H8 (IR) |
| Operating humidity ( non-condensing ) | 15 % to 90 % RH |
