Dissolution Tester NDST-104

Dissolution Tester NDST-104 comes with an automated head movement, has a configuration of eight vessels and six poles. The basket units and paddle units are made of stainless steel that aids in resistance to high temperature. Speed ranging from 20 to 200 rpm with a temperature ranging at 45 ̊C.

Get Quote Download Catalog

Specifications

Configuration	Eight vessels and eight poles
Head Movement	Auto
Speed Range	20 to 200rpm
Speed Accuracy	± 2rpm
Temperature Range	RT 45.0℃
Temperature Accuracy	± 0.3℃
Time Range	Nine points (1 to 999) min
Timer Accuracy	± 0.3%
Basket Radial Run-Out	± 1 mm
Paddle Radial Run-Out	± 0.5 mm
Axis Rotation Concentricity	± 2.0 mm
Electrical Supply	AC 220 V 50 HZ
Heating Power	1000 W
Power	1200 W
Net Weight/Gross Weight	58 kg/96 kg
Overall Dimension	96 × 52 × 48 cm
Packing Dimension	120 × 63 × 60 cm

Features

✔ Stainless steel basket and paddle
✔ Circulating pump to ensure the stability of water temperature
✔ Automatical intelligent control
✔ Adjustable temperature, rotation speed and timer setting
✔ Auto test, diagnose and alarm system
✔ Can continuously work for more than 24 hours
✔ Timer can be preset at many points, and can be run to next test point automatically
