Mechanically Stirred High Pressure Reactor NSHPR-101 comes with a 50 L capacity and a durable PTFE reactor liner. It offers both positive and negative stirring to ensure more uniform mixing. Our unit supports remote operation for convenient control over a wide range. It includes an automatic pressure release system for enhanced safety. This reactor is equipped with an inflatable seal hose to ensure a secure and leak-free connection.
| Capacity | 50 ml |
| Display Precision | ±1°C |
| Kettle Body Material | SS316L / Pure Titanium / Hastelloy (optional) |
| Stirring Type | Bottom magnetic + top mechanical stirring |
| Temperature Range | 300°C to 500°C (optional) |
| Working Pressure | 10 MPa / 50 MPa (optional) |
| Valve & Connection Material | SS316L Stainless Steel |
| Reactor Chamber | Fully wrapped PTFE |
| Dimensions | Ø60 × 80 |
Mechanically Stirred High Pressure Reactor NSHPR-101 is suitable for high-temperature and pressure synthesis, hydrogenation, and catalytic reactions in chemical, pharmaceutical, and energy research.
