Benchtop Freeze Dryer NBFD-105

Name: Benchtop Freeze Dryer NBFD-105
Brand: Labnics
SKU: NBFD-105
Rating: 5 (733 reviews)

Benchtop Freeze Dryer NBFD-105 is designed with a -80°C condenser and a capacity range of 6 kg. It includes stainless steel trays and shelves for corrosion resistance. Our benchtop freeze dryer features a colour LCD touchscreen for real-time monitoring. It provides a USB port for easy data transfer in Excel format. The unit achieves a final vacuum of <1 Pa (0.001 mbar) and is equipped with 250 ml, 500 ml, and 1000 ml flasks, with three pieces provided for each capacity

$7,900.00

Data Sheet

Specifications

Minimum Condenser Temperature	-80°C
Final Vacuum	<1 Pa (0.001 mbar)
Condenser Ice Capture	6 kg/24h
Display	LCD Touch Screen (English)
Parameters Displayed	Temperature and Vacuum Degree
Data Output	USB Port
Vacuum Pump	120 L/S with connection accessories
Isolation System	KF25 isolation to prevent oil and air contamination
Refrigerant	CFC-free
Drainage Valve Material	Stainless Steel
Defrosting	Off-cycle defrosting
Voltage	220V / 50 Hz, Single Phase
Power	2100W
Dimensions (D × W × H)	800 × 560 × (500 + 460) mm
Net Weight	80 kg
Gross Weight	110 kg

Features

Transparent chamber
CFC free refrigerant
Stain-less steel
Connectivity with USB

Applications

Benchtop Freeze Dryer NBFD-105 is widely used in pharmaceutical, biological, chemical, and food industries for freeze drying and long-term preservation of heat-sensitive samples. It is suitable for lyophilization of vaccines, serum, bacteria, enzymes, injectable drugs, and samples stored in ampoules while maintaining their original properties after rehydration. The system is ideal for research laboratories, universities, biotechnology institutes, and pilot-scale applications requiring efficient vacuum freeze drying with data monitoring and export functionality.

Standard Accessories

Accessory	Unit	Quantity
250 ml Flasks	Pieces	3
500 ml Flasks	Pieces	3
1000 ml Flasks	Pieces	3
Ampoule Adapters	Pieces	3
