Anemometer NAM-100
Anemometer NAM-100 measures air velocity from 0.4 to 45.0 m/s, providing accurate readings. It operates effectively within a temperature range of 0℃ to 50℃ for optimal performance. This multifunctional unit offers versatile measurement options to accommodate different needs. It includes a precision thermistor that measures ambient temperature for reliable results. Our unit features a 4-digit LCD for clear and easy data monitoring.
| Measurement Units |
Air Velocity: m/s, km/h, ft/min, knots Air Flow: CMM (m³/min); CFM (ft³/min) Beaufort Scale: Force Wave Height: m Temp: ℃ & F |
| Air Velocity Measurement Range | 0.4 to 45.0 m/s |
| Air Velocity Resolution | 0.1 |
| Air Velocity Accuracy | ± (2%n + 0.5 m/s) |
| Air Flow Measurement Range | 0 to 9999 CMM |
| Air Flow Resolution | 0.001 to 1 |
| Air Flow Accuracy | ± (2%n + 0.5 m³/min) |
| Beaufort Scale Measurement Range | 0 to 12 |
| Beaufort Scale Resolution | 0.1 |
| Beaufort Scale Accuracy | ± 0.5 |
| Wave Height Measurement Range | 0 to 14 m |
| Wave Height Resolution | 0.1 |
| Wave Height Accuracy | ± 0.1 |
| Air Temperature Measurement Range | -10 to 60°C |
| Air Temperature Resolution | 0.1°C |
| Air Temperature Accuracy | 0.5°C |
| Operating Temperature | 32℉ to 122℉ (0℃ to 50℃) |
| Operating Humidity | Max. 80% RH |
| Sampling Rate | Reading per second approx. |
| Sensor Head | 72 mm Diameter |
| Sensors |
Air velocity/flow sensor: Conventional angled vane arms with low-friction ball bearing Temperature sensor: Precision thermistor |
| Automatic Power Off | 0 to 9 minutes set by users |
| Data Output | RS 232 C serial interface |
| Display | 0.5" (13 mm) 4-digit LCD |
| Power | 4 × 1.5AAA batteries |
| Dimensions | 156 × 67 × 28 mm (6.1 × 2.6 × 1.1") |
| Weight | 260g (including batteries & probe) |
Anemometer is used to measure wind speed and direction, essential for weather forecasting and environmental studies. It helps optimize airflow in various applications, including meteorology and HVAC systems.
Operational Manual
Cable + Software for RS232C
