Air Quality Monitor NAQM-100

Air Quality Monitor NAQM-100

Air Quality Monitor NAQM-100

Air Quality Monitor NAQM-100 offers a detection accuracy of ±3% and a resolution of 0.001ppm for a wide range of gases within specific ranges. It delivers real-time data with a response time of ≤30 seconds. Its continuous monitoring is displayed on a 7-inch color touch screen, featuring adaptive displays and automatic page turning. Made with anti-corrosion and sun protection properties, it can be installed via ceiling or wall mounts. Our air quality monitor detects meteorological parameters and particulate matter, making it a comprehensive environmental monitoring tool.

Specifications
Gas Detection Ozone (Oᴣ), sulfur dioxide (SO₂), nitrogen dioxide (NO₂), carbon monoxide (CO), TVOC, etc.
Measuring Range Oᴣ: 0 to 1ppm
SO₂: 0 to 5ppm
NO₂: 0 to 5ppm
CO: 0 to 10ppm
Resolution Oᴣ: 0.001ppm
SO₂: 0.001ppm
NO₂: 0.001ppm
CO: 0.001ppm
Measuring Principle Electrochemical, infrared, PID photoion
Detection Accuracy ±3%
Response Time ≤ 30s
Meteorological Detection Temperature, humidity, noise, air pressure, light intensity, wind speed, wind direction
Particle Detection Temperature: -40℃ to +120℃
Humidity: 0%RH to 99%RH
Noise: 30dB to 130dB
Air pressure: 0 to 120Kpa
Light intensity: 0 to 200000Lux
Wind speed: 0 to 60m/s
Wind direction: North wind, northeast wind, east wind, southeast wind, south wind, southwest wind, west wind, northwest wind
Sampling Method Temperature: 1℃
Humidity: 1%RH
Noise: 1dB
Air pressure: 1Kpa
Light intensity: 1Lux
Wind speed: 0.1m/s
Pump Flow Rate Thermocouple and mechanical
Monitoring Way PM2.5, PM10, TSP
Working Time PM2.5: 0 to 1000µg/m³
PM10: 0 to 1000µg/m³
TSP: 0 to 1000µg/m³
Display Screen PM2.5: 1µg/m³
PM10: 1µg/m³
TSP: 1µg/m³
Display Mode Laser
Signal Output ≤ 30s
Working Current Pump suction
Working Voltage 0.5L/min (gas); 1.8L/min (particles/dust)
Working Temperature Continuous automatic real-time monitoring
Working Humidity 24 hours continuous work
Alarm Type 7-inch color touch screen
Material Adaptive display channel number, automatic page turning
Installation Way RS48 and relay
Oil Water Dust Filter <100 Ma (Max)
Power Supply Internal: 24VDC; External: 220V/50HZ AC
Dimension -10℃ to 55℃
Weight 0 to 95%RH
Features
Applications

Our Air Quality Monitor is ideal for various applications, including urban air quality monitoring, grid assessments by management departments, monitoring in populated areas like schools and hospitals, atmospheric evaluations in industrial settings, and environmental quality assessments in open spaces and construction sites.

Standard Accessories

Data logger


Software
RS485 modbus cable data transmission
2m carbon steel brackets
